Specifications

Dimensions

Deck Width	83 inches
Deck Length	22 feet
Deck Height	~24–26 inches
Overall Length	~28–30 feet

Axles

Quantity	2
Rating	7,000 lb Dexter axles each
Brakes	Electric brakes on both axles
Hubs	EZ-Lube hubs

GVWR & Capacity

GVWR	14,000 lb
Payload Capacity	~10,500–11,000 lb depending on installed options

Tires & Wheels

Tire Size	ST235/80R16 (10-ply)
Wheel Type	8-lug wheels

Frame & Construction

Frame	6" or 8" channel frame (CH-series standard)
Crossmembers	3" channel, spaced 16" on center
Floor	Treated wood deck
Fenders	Removable diamond plate fenders
Finish	Powder-coated

Loading Features

Ramps	Heavy-duty stand-up equipment ramps
Stabilizers	Rear stabilizer jacks (if equipped)
D-Rings	Multiple welded tie-down points

Coupler & Jack

Coupler	Adjustable 2-5/16"
Jack	10k drop-leg jack (single or dual depending on options)

Electrical System

Lighting	LED lighting package
Wiring	Cold-weather sealed wiring harness

Standard Equipment

	Spare tire mount
	afety chains
	Breakaway system

Certain features may require an additional add-on package that may not be included in the retail or sale price. Please contact the dealership for full details.
